Automatic tin can top and bottom line

The auto tin can top and bottom making line is suitable to match our auto canbody making line,production capacity is 30-120 cans per min. We supplied our tin can top and bottom machines to Saudi Arabia, Dubai, Vietnam, Malaysia, India, Mexico, Jordan and so on.

MESSAGE

CONTACT

Product Details

1. Fully Automatic Sheet Feeding Machine

	Speed:	60-120pcs per min
	Applicable Top&Bottom Shape:	Round/Square
	Power:	6kw
	Net weight:	1000kgs
	Dimension:	2500x1500x1600mm

2. Automatic Sheet Feeding Machine

	Speed:	30-80pcs per min
	Applicable Top&Bottom Shape:	Round/Square
	Power:	3kw
	Net weight:	500kgs
	Dimension:	1600x1500x1600mm

3.Automatic Strip Feeding Machine

	Speed:	30-80pcs per min
	Applicable Top&Bottom Shape:	Round/Square
	Power:	3kw
	Net weight:	500kgs
	Dimension:	1500x1200x1600mm

4. Automatic Round Lid Curling Machine

Model	GT3B3	GT3B5	GT3B8
Capacity(pcs per min):	80-120
Applicative Diameter(mm):	Φ52-Φ108	Φ108-Φ153	Φ153-Φ180
Power:	1.5kw
Net weight:	200kgs
Dimension:	1200x1100x1100mm

5.Automatic Round Can Top&Bottom Lining&Drying Machine

Model	GT3C3	GT3C5	GT3C8
Capacity(pcs per min):	80-120
Applicative Diameter(mm):	Φ52-Φ99	Φ99-Φ153	Φ153-Φ180
Power:	15kw
Net weight:	1000kgs
Dimension:	1800x980x2980mm
